General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC7015#12D | B.S | 12 | 7.0~13.8 | 0.08 | 0.96 | 2800 | 23.38 | 0.062 | 0.089 | 2.27 | 26 | 48 |
DC7015#12L | B.S | 12 | 7.0~13.8 | 0.14 | 1.68 | 3300 | 28.18 | 0.798 | 0.123 | 3.12 | 28 | 48 |
DC7015#12M | B.S | 12 | 7.0~13.8 | 0.18 | 2.16 | 3800 | 33.2 | 0.94 | 0.162 | 4.12 | 33 | 48 |
DC7015#12H | B.S | 12 | 7.0~13.8 | 0.26 | 3.12 | 4300 | 37.54 | 1.063 | 0.21 | 5.33 | 36 | 48 |
DC7015#12U | B.S | 12 | 7.0~13.8 | 0.37 | 4.44 | 5200 | 45.45 | 1.287 | 0.306 | 7.79 | 41 | 48 |
DC7015#24D | B.S | 24 | 14.0~27.6 | 0.06 | 1.44 | 2800 | 23.38 | 0.062 | 0.089 | 2.27 | 26 | 48 |
DC7015#24L | B.S | 24 | 14.0~27.6 | 0.09 | 2.16 | 3300 | 28.18 | 0.798 | 0.123 | 3.12 | 28 | 48 |
DC7015#24M | B.S | 24 | 14.0~27.6 | 0.12 | 2.88 | 3800 | 33.2 | 0.94 | 0.162 | 4.12 | 33 | 48 |
DC7015#24H | B.S | 24 | 14.0~27.6 | 0.15 | 3.6 | 4300 | 37.54 | 1.063 | 0.21 | 5.33 | 36 | 48 |
