General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC6025#12 | B.S | 12 | 7.0~13.8 | 0.14 | 1.68 | 4000 | 23.38 | 0.662 | 0.211 | 5.35 | 32 | 56 |
DC6025#24M | B.S | 24 | 14.0~27.6 | 0.07 | 1.68 | 3600 | 19.78 | 0.56 | 0.155 | 3.93 | 32 | 56 |
DC6025#24H | B.S | 24 | 14.0~27.6 | 0.11 | 2.64 | 5000 | 27.55 | 0.78 | 0.294 | 7.47 | 38 | 56 |
DC6025#24U | B.S | 24 | 14.0~27.6 | 0.17 | 4.08 | 6000 | 34.15 | 0.967 | 0.422 | 10.73 | 45 | 56 |
