General Specification
Frame / Impeller: Plastic
Lead Wire: UL1007 AWG#26 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC4020-5B1 | B.S | 5 | 3.5~5.5 | 0.1 | 0.5 | 5000 | 5.54 | 0.157 | 0.136 | 3.45 | 27 | 24 |
DC4020#12L | B.S | 12 | 7.0~13.8 | 0.05 | 0.6 | 5000 | 5.54 | 0.157 | 0.136 | 3.45 | 27 | 24 |
DC4020#12M | B.S | 12 | 7.0~13.8 | 0.06 | 0.72 | 6300 | 7.17 | 0.23 | 0.218 | 5.54 | 35 | 24 |
DC4020#12H | B.S | 12 | 7.0~13.8 | 0.1 | 1.2 | 8000 | 9.43 | 0.268 | 0.354 | 9 | 38 | 24 |
DC4020#24L | B.S | 24 | 14.0~27.6 | 0.04 | 0.96 | 5000 | 5.54 | 0.157 | 0.136 | 3.45 | 27 | 24 |
DC4020#24M | B.S | 24 | 14.0~27.6 | 0.07 | 1.68 | 8200 | 9.43 | 0.267 | 0.354 | 9 | 35 | 24 |
DC4020#24H | B.S | 24 | 14.0~27.6 | 0.09 | 2.16 | 10000 | 10.1 | 0.286 | 0.416 | 10.57 | 38 | 24 |
