General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC9225#12D | B.S | 12 | 7.0~13.8 | 0.07 | 0.84 | 2100 | 37.08 | 1.05 | 0.1 | 2.53 | 25 | 78 |
DC9225#12L | B.S | 12 | 7.0~13.8 | 0.11 | 1.32 | 2450 | 43.79 | 1.24 | 0.13 | 3.25 | 31 | 78 |
DC9225#12M | B.S | 12 | 7.0~13.8 | 0.16 | 1.92 | 2850 | 51.21 | 1.45 | 0.177 | 4.5 | 37 | 78 |
DC9225#12H | B.S | 12 | 7.0~13.8 | 0.25 | 3 | 3200 | 57.92 | 1.64 | 0.221 | 5.62 | 41 | 78 |
DC9225#12U | B.S | 12 | 7.0~13.8 | 0.4 | 4.8 | 3800 | 67.8 | 1.92 | 0.302 | 7.67 | 47 | 78 |
DC9225#24D | B.S | 24 | 14.0~27.6 | 0.06 | 1.44 | 2100 | 37.08 | 1.05 | 0.1 | 2.53 | 25 | 78 |
DC9225#24L | B.S | 24 | 14.0~27.6 | 0.08 | 1.92 | 2450 | 43.79 | 1.24 | 0.13 | 3.25 | 31 | 78 |
DC9225#24M | B.S | 24 | 14.0~27.6 | 0.1 | 2.4 | 2850 | 51.21 | 1.45 | 0.177 | 4.5 | 37 | 78 |
DC9225#24H | B.S | 24 | 14.0~27.6 | 0.13 | 3.12 | 3200 | 57.92 | 1.64 | 0.221 | 5.62 | 41 | 78 |
DC9225#48L | B.S | 48 | 28.0~56.0 | 0.05 | 2.4 | 2100 | 37.08 | 1.05 | 0.1 | 2.53 | 31 | 78 |
DC9225#48M | B.S | 48 | 28.0~56.0 | 0.05 | 2.4 | 2450 | 43.79 | 1.24 | 0.13 | 3.25 | 37 | 78 |
DC9225#48H | B.S | 48 | 28.0~56.0 | 0.06 | 2.88 | 2850 | 51.21 | 1.45 | 0.177 | 4.5 | 41 | 78 |
DC9225#48U | B.S | 48 | 28.0~56.0 | 0.08 | 3.84 | 3200 | 57.92 | 1.64 | 0.221 | 5.62 | 47 | 78 |
